Control valve for water and steam – Type 421 KFM Regelungstechnik gmbh Control Valve (Germany)
- Material: GGG-40.3.
- Pressure scale: PN 16, PN 25.
- Flange diameter: DN 15 – DN 150.
- Kvs: 4 – 330 m 3 /h.
- Flanges are made according to DIN EN 1092-2.
- Working depth according to DIN EN 558.
- Source: 230V/50…60Hz.
- Feedback signal: 4…20mA/ 0…10V.
Control valve for heat transfer oil – Type 451 KFM Regelungstechnik gmbh Control Valve (Germany)
- Material: GGG-40.3.
- Pressure scale: PN 16, PN 25.
- Flange diameter: DN 15 – DN 150.
- Kvs: 4 – 330 m 3 /h.
- Flanges are made according to DIN EN 1092-2.
- Working depth according to DIN EN 558.
- Source: 230V/50…60Hz.
- Feedback signal: 4…20mA/ 0…10V.
Control valve for water and steam – Type 431 KFM Regelungstechnik gmbh Control Valve (Germany)
- Material: GGG-40.3.
- Pressure scale: PN 16, PN 25.
- Flange diameter: DN 15 – DN 150.
- Kvs: 4 – 330 m 3 /h.
- Flanges are made according to DIN EN 1092-2.
- Working depth according to DIN EN 558.
- Source: 230V/50…60Hz.
- Feedback signal: 4…20mA/ 0…10V.
Control valve for heat transfer oil – Type 461 KFM Regelungstechnik gmbh Control Valve (Germany)
- Material: GGG-40.3.
- Pressure scale: PN 16, PN 25.
- Flange diameter: DN 15 – DN 150.
- Kvs: 4 – 330 m 3 /h.
- Flanges are made according to DIN EN 1092-2.
- Working depth according to DIN EN 558.
- Source: 230V/50…60Hz.
- Feedback signal: 4…20mA/ 0…10V.
Control valve for heat transfer oil – Type 462 KFM Regelungstechnik gmbh Control Valve (Germany)
- Material: GGG-40.3.
- Pressure scale: PN 16, PN 25.
- Flange diameter: DN 32 – DN 150.
- Kvs : 12 – 250 m 3 /h.
- Flanges are made according to DIN EN 1092-2.
- Working depth according to DIN EN 558.
- Source: 230V/50…60Hz.
- Feedback signal: 4…20mA/ 0…10V.
3 Way Linear Valve With Electric Control – Diverting Valve 432 KFM Regelungstechnik gmbh Control Valve (Germany)
- Proportional valve type
- DN15-150; PN16/25
- Valve body material: EN-GJS-400-18-LT
- Water application. hot water, saturated steam Withstanding
- pressure: PN16, PN25
- Seal material: PTFE-V-ring unit
- Actuator: with manual emergency operation and load dependent limit switch
- Valve closing force: 2000 N
- Input power: 12 VA
- Force options: 4000 N / 28 VA (appendix …c); 5500 N / 28 VA (appendix …d)
- Power supply: 230V/50…60Hz Power
- options: 115V/50…60Hz, 24V/50…60Hz, 24VDC
- Motor DIN EN 60034-1: S1 – 100%
- Protection level DIN EN 60529: IP65
- Optional accessories: Controller (Positioner); Solenoid valve (Solenoid valve); Limit switches;
- Flange connection: DIN standard; optional standard ANSI / JIS
- Origin: KFM – Germany
Electrically controlled 3-way linear valve-Mixing valve type 561 KFM Regelungstechnik gmbh Control Valve (Germany)
- Mixing valve type 561
- DN15-100; PN16/25
- Valve body material: EN-GJS-400-18-LT
- Heat transfer oil application Bearing
- pressure: PN16, PN25
- Seal material: Bellow
- Actuator: with emergency closing function (straight line closing) A-AB due to power failure) and integrated manual emergency function
- Valve closing force: 2800 N
- Closing force options: DN15 … 50: 17VA; DN65 … 100: 28VA
- Power supply: 230V / 50 … 60Hz, Optional: 24VAC (for positioner 59sr only)
- Degree of protection DIN EN 60529: IP54
- Optional accessories: Positioner; Electromagnetic valve; Switch journey;
- Standard flange connection ANSI / JIS (on request)
- Origin: KFM – Germany
Electrically controlled 3-way linear valve-Proportional mixer valve type 531 – KFM Regelungstechnik gmbh Control Valve (Germany)
- Mixing valve type 531
- DN15-100; PN16 / 25
- Valve body material: EN-GJS-400-18-LT
- Application for water, hot water, saturated steam Withstanding
- pressure: PN16, PN25
- Seal material: PTFE-V
- Actuator: with function emergency closing (A-AB straight line closing due to power failure) and integrated manual emergency function
- Valve closing force: 2800 N
- Closing force options: DN15 … 50: 17VA; DN65 … 100: 28VA
- Power supply: 230V / 50 … 60Hz, Optional: 24VAC (59sr positioner only)
- Degree of protection DIN EN 60529: IP65
- Optional accessories: Positioner; Electromagnetic valve; Switch journey;
- Standard flange connection ANSI / JIS (on request)
- Origin: KFM – Germany
