VMP Plastic Air Pinch Valves

.

VMP Series Air Pinch Valves are a reliable and economic valve for a range of industrial applications. From 3/8” – 2” diameters [10mm – 50mm].

Applications:

.

Advantages:

• VMP Pinch Valves are light weight, inexpensive valves that have a sealed shutoff and full bore opening when opened. The sleeves do not impede product flow and are come in a range of sleeve options for abrasive materials, strong acids and bases and even high temperature applications.
  • Pinch valve sleeves (liners) can be easily replaced. See step-by-step instructions.

VMP Pinch Valves are constructed of 3 plastic body options:

• Natural White Plastic for Food and Sanitary Applications, FDA Approved
  • Black Plastic for Industrial Applications
  • Black Conductive Plastic for Class I and Class II Explosion Proof (XP) areas

Sleeve Options for VMP Valves:

VMP Valves by Size and Connection Type

Valve Sizes  Inch [mm]	Threaded Ends  NPT (tapered) or BSPP (G)*	Socket Ends  Stainless Steel	Max Recommended  Line Pressure	CAD Drawings
3/8 Inch [10 mm]	3/8” NPT or G	Yes	90 PSI	DN 10
1/2 Inch [15 mm]	1/2” NPT or G	Yes	90 PSI	DN 15
3/4 Inch [20 mm]	3/4” NPE or G	See VMC valves	90 PSI	DN 20
1 Inch [25 mm]	1” NPT or G	See VMC valves	90 PSI	DN 25
1-1/4 Inch [32 mm]	1-1/4” NPT or G	See VMC valves	70 PSI	DN 32
1-1/2 Inch [40 mm]	1-1/2” NPT or G	See VMC valves	70 PSI	DN 40
2” Inch [50 mm]	2” NPT or G	See VMC valves	70 PSI	DN 50

*Note BSPP (British Standard Parallel Pipe) is designated as G thread
